Тех. характеристики
| Summary |
Intel® Trusted Execution TechnologyIntel® Trusted Execution Technology for safer computing is a versatile set of hardware extensions to Intel® processors and chipsets that enhance the digital office platform with security capabilities such as measured launch and protected execution. It enables an environment where applications can run within their own s
|
| Processor ARK ID |
134599
|
| CPU Family name |
Intel Core i9
|
| Model number |
i9-12900K
|
| Cooler included |
No
|
| Market segment |
Desktop
|
| Maximum internal memory |
128 GB
|
| Maximum number of DMI lanes |
8
|
| Performance-core base frequency |
3.2 GHz
|
| Processor boost frequency |
5.2 GHz
|
| Processor cores |
16
|
| Maximum operating temperature |
100 °C
|
| OpenCL version |
3.0
|
| Maximum number of PCI Express lanes |
20
|
| Intel® Turbo Boost Technology |
2.0
|
| Component for |
PC
|
| Processor Threads |
24
|
| Memory bandwidth (max) |
76.8 GB/s
|
| Bus Type |
DMI4
|
| Efficient-core base frequency |
2.4 GHz
|
| Processor family |
Intel® Core™ i9
|
| Efficient-core boost frequency |
3.9 GHz
|
| Processor manufacturer |
Intel
|
| Use conditions |
PC/Client/Tablet/Workstation
|
| Performance-core boost frequency |
5.1 GHz
|
| Processor model |
i9-12900K
|
| Processor cache type |
Smart Cache
|
| Efficient cores |
8
|
| ECC |
Yes
|
| Processor cache |
30 1. Quick guide2. Driver CD
|
| Maximum turbo power |
241 W
|
| Memory bandwidth supported by processor (max) |
76.8 GB/s
|
| Processor codename |
Alder Lake
|
| CPU configuration (max) |
1
|
| Performance cores |
8
|
| Тип устройства |
LGA 1700
|
| L2 cache |
14336 KB
|
| Processor base power |
125 W
|
| Processor generation |
12th gen Intel® Core™ i9
|
| Harmonized System (HS) code |
85423119
|
| Discrete graphics card |
No
|
| Discrete graphics card model |
Not available
|
| On-board graphics card model |
Intel UHD Graphics 770
|
| Scalability |
1S
|
| Non-ECC |
Yes
|
| Package Type |
Box
|
| Tjunction |
100 °C
|
| Processor operating modes |
64-bit
|
| Unit Calculated Weight |
0.5 kg
|
| Memory channels |
Dual-channel
|
| Units per Shipping Box |
1
|
| Maximum internal memory supported by processor |
128 GB
|
| PCI Express slots version |
4.0/5.0
|
| On-board graphics card DirectX version |
12.0
|
| PCI Express configurations |
1x16+1x4/2x8+1x4
|
| On-board graphics card dynamic frequency (max) |
1.55 MHz
|
| On-board graphics card ID |
0x4680
|
| On-board graphics card maximum resolution (DisplayPort) |
7680 x 4320 pixels
|
| On-board graphics card maximum resolution (eDP - Integrated Flat Panel) |
5120 x 3200 pixels
|
| Unit Calculated Volume |
0.002574/0.003859 cubm
|
| On-board graphics card maximum resolution (HDMI) |
4096 x 2160 pixels
|
| On-board graphics card OpenGL version |
4.5
|
| On-board graphics card outputs supported |
DisplayPort 1.4/DisplayPort 1.4a/Embedded DisplayPort (eDP)/Embedded DisplayPort (eDP) 1.4b/HDMI 2.1
|
| On-board graphics card refresh rate at maximum resolution (DisplayPort) |
60 Hz
|
| On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel) |
120 Hz
|
| Number of displays supported (on-board graphics) |
4
|
| On-board graphics card base frequency |
300 MHz
|
| On-board graphics card refresh rate at maximum resolution (HDMI) |
60 Hz
|
| Direct Media Interface (DMI) Revision |
4.0
|
| Intel® Optane™ Memory Ready |
Yes
|
| Supported instruction sets |
AVX 2.0/SSE4.1/SSE4.2
|
| Export Control Classification Number (ECCN) |
5A992.C
|
| Thermal solution specification |
PCG 2020A
|
| Embedded options available |
No
|
| Enhanced Intel SpeedStep Technology |
Yes
|
| Execute Disable Bit |
Yes
|
| Intel 64 |
Yes
|
| Intel Turbo Boost Max Technology 3.0 |
Yes
|
| Intel Trusted Execution Technology |
Yes
|
| Intel Virtualization Technology (VT-x) |
Yes
|
| Intel Virtualization Technology for Directed I/O (VT-d) |
Yes
|
| Intel VT-x with Extended Page Tables (EPT) |
Yes
|
| Intel vPro® Enterprise Platform Eligibility |
Yes
|
| Intel® Active Management Technology (Intel® AMT) |
Yes
|
| Commodity Classification Automated Tracking System (CCATS) |
G167599
|
| Intel® Boot Guard |
Yes
|
| Intel® Control-flow Enforcement Technology (CET) |
Yes
|
| Idle States |
Yes
|
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU |
Yes
|
| Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 |
Yes
|
| Intel Enhanced Halt State |
Yes
|
| Intel® Hardware Shield Eligibility |
Yes
|
| Intel® Stable IT Platform Program (SIPP) |
Yes
|
| Intel® One-Click Recovery |
Yes
|
| On-board graphics card |
Yes
|
| Intel® AES New Instructions (Intel® AES-NI) |
Yes
|
| Intel Stable Image Platform Program (SIPP) |
Yes
|
| Intel® Hyper Threading Technology (Intel® HT Technology) |
Yes
|
| Intel® Speed Shift Technology |
Yes
|
| Intel® OS Guard |
Yes
|
| Intel® Standard Manageability (ISM) |
Yes
|
| Intel® Secure Key |
Yes
|
| Intel® vPro™ Platform Eligibility |
Yes
|
| Intel® Thread Director |
Yes
|
| Memory types supported by processor |
DDR4-SDRAM/DDR5-SDRAM
|
| Thermal Monitoring Technologies |
Yes
|
| Intel® Threat Detection Technology (TDT) |
Yes
|
| Intel® Total Memory Encryption - Multi Key |
Yes
|
| Intel® Clear Video HD Technology (Intel® CVT HD) |
Yes
|
| Intel® Turbo Boost Max Technology 3.0 frequency |
5.2 GHz
|
| Intel® Virtualization Technology with Redirect Protection (VT-rp) |
Yes
|
| Intel® Total Memory Encryption |
Yes
|
| Intel® Volume Management Device (VMD) |
Yes
|
| Mode-based Execute Control (MBE) |
Yes
|
| Launch date |
Q4'21
|
| Intel® Quick Sync Video Technology |
Yes
|
| Status |
Launched
|
| Graphics output |
eDP 1.4b, DP 1.4a, HDMI 2.1
|
| OpenGL support |
Yes
|
| Number of execution units |
32
|
| Target market |
Gaming, Content Creation
|
|
